DIY Doublet Achromatic Objective Lens 50mm

Original price was: $13.00.Current price is: $8.00.

38% Off

Support global shipping！This is customized optical lens.The Achromatic Lens is used for binocular&monocular Telescope objective lens，etc.
——-
Model:A-002
Size:φ50,φ60,φ70,φ90,etc
Price:by case
Min.order Quantity: 1 pieces
Lead time:1-4 weeks or depends on order quantity

Categories:

Description

Achromatic Lenses are used to minimize or eliminate chromatic aberration. The achromatic design also helps minimize spherical aberrations. Achromatic Lenses are ideal for a range of applications, including fluorescence microscopy, image relay, inspection, or spectroscopy. An Achromatic Lens, which is often designed by either cementing two elements together or mounting the two elements in a housing, creates smaller spot sizes than comparable singlet lenses.

Specification of Achromatic Lens：
Material: BK7, LaSFN9 glass,Ohara S-LAH71 glass or other optical glass
Surface Quality: 20-10
Diameter: 1.8mm-140mm

Specification

Diameter Tolerance 1-600±0.02MM
Clear Aperture >90%
Thickenss Tolerance 0.5-50±0.02MM
Surface Flatness  1/10LAMBDA
SufaceQuality 20-10
 Material N-BK7,FUSED SILICA,SAPPHIRE, CAF2,MGF2,ZNSE
Beveling 45°X0.2MM
Coating Coating Reflective Coating Dichroic Film
Inspection:Each lens be tested before packing,a formal tested report will be provided.

Application of our lenses:avionics,astronomy,military,medical,scientifics,laser etc…

Q1:Can you send me free samples or Can i have an sample order ?

A: Yes, We accept sample orders, and we’re also willing to send you free sample to  test and check its quality . if we don’t have the item in stock , then you could place an sample order.

Q2: How many days can i get my package after placing order?

A: If the order needs customized also the quantity is big. it will take around 10-30 wroking days to produce then shipping.

Q3: OEM services available?

A: Sure, please send us your design paper on platform to confirm more details information.

Q4:We have a commercial project,Can you help me offer an optical design solution ?

A:Yes, we have professional experts who are engaged in optical design for many years , please send us more detail of your project,we will supply our most suitable solutions for you.

Q5: What shipping methods do you have?

A: For small quanities or sample could by express such as: Fedex, UPS, DHL, EMS, etc. Large scale quantity in your demands:by sea/train ,or by air.In your request
